FAG UCP209-27-J7 Housing and Bearing UC209-27 P209 ID 1.6875 Inch OD 189.7 Inch

Description:

• Brand FAG
• Item Number UCP209-27-J7 FAG
• Manufacturer Part Number 0812155170000
• Also known as UC209-27 + P209
• EAN 4047643261883
• Category Housing and Bearing (assembly)

Weight and Dimensions

• Inner (d) MM 42,86
• Outer (D) MM 189,7
• Width (B) MM 51,2
• Inner (d) Inch 1.6875
• Outer (D) Inch 7.4688
• Width (B) Inch 2.0156
• Weight (kg) 2.2

Product Properties

• Seal 2F – Standard Seal for Y-bearings
• Lubrication Standard Lubrication
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Length total (L) mm 190
• Height (H 2) mm 106
• ECLASS number 23-05-16-01
• ECLASS2 number 23-05-16-01
• Medias description Plummer block housing units UCP, cast iron housing, with long base, radial insert ball bearing with grub screws in inner ring, RSR seals

Suffix description

• J7This Suffix Is The Standard With A Better Fitting In The Housing

Product description

The UCP209-27-J7 FAG is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing’s lifespan.

Package Includes: ONE (1) FAG BEARING and HOUSING UCP209-27-J7
