SKF N305 ECP Cylindrical Roller Bearing, Single Row 25x62x17 mm

Description:

Brand: SKF
Part Number: N305ECP
EAN: 7316577059017
Manufacturer Part Number: 7316577059017
Category: Cylindrical Roller Bearing, Single Row
Product ID: 10039791
Country of Origin: Germany
Customs Tariff Number: 8482 5000

Inner Diameter (d): 25 mm / 0.9843 in
Outer Diameter (D): 62 mm / 2.4409 in
Width (B): 17 mm / 0.6693 in
Weight: 0.234 kg

Bearing Type: Single Row Cylindrical Roller Bearing
Design: N Design
Rows of Rollers: Single Row
Bore Type: Cylindrical Bore
Seal Type: Open / No Seal
Cage Type: Glass Fiber Reinforced Polyamide 6,6 Cage
Radial Internal Clearance: CN Normal Clearance
Precision: Standard Precision
Dimensional Accuracy: P0 / PN / ABEC 1
Running Accuracy: P6 / ABEC 3
Heat Stabilization: None, up to 120 °C
Outer Ring: Without Groove / Lubrication Holes
Current Insulation: No
Version: Explorer
Construction: Improved Internal Design
Temperature Range: -30 °C to +120 °C

Suffix Meaning:
EC: Optimized internal design with more and/or larger rollers and modified roller/end flange contact
P: Injection molded cage of glass fiber reinforced polyamide 6,6, roller centered

Description:
The SKF N305ECP is a single row cylindrical roller bearing with cage designed for high radial loads and higher operating speeds than full-complement cylindrical roller bearings. Its cage keeps the rollers separated, reducing friction and heat generation while improving speed capability.

This bearing features an N design, meaning the inner ring has two rigid ribs and the outer ring has none. Because of this configuration, it supports radial loads only and allows axial displacement of the shaft relative to the housing in both directions. This makes it an excellent choice as a floating bearing in applications where thermal expansion must be accommodated.

Typical applications include gearboxes, agricultural machinery, pumps, compressors, and electric motors.

   PACKAGE INCLUDES: ONE (1) SKF Bearing N305 ECP
