SKF NU2206 ECJ Cylindrical Roller Bearing, Single Row 30x62x20 mm

Description:

Brand: SKF
Part Number: NU2206ECJ
EAN: 7316577113641
Manufacturer Part Number: 7316577113641
Category: Cylindrical Roller Bearing, Single Row
Product ID: 10088465
Country of Origin: Germany
Customs Tariff Number: 8482 5000

Inner Diameter (d): 30 mm / 1.1811 in
Outer Diameter (D): 62 mm / 2.4409 in
Width (B): 20 mm / 0.7874 in
Weight: 0.268 kg

Bearing Type: Single Row Cylindrical Roller Bearing
Design: NU Design / Floating Bearing
Bore Type: Cylindrical Bore
Seal Type: Open / No Seal
Outer Ring: Without Groove / Lubrication Holes
Roller Rows: Single Row
Cage Type: Pressed Steel Cage
Cage Design: Roller Centered, Unhardened
Radial Internal Clearance: CN / Normal Internal Play
Precision: Standard Precision
Dimensional Accuracy: P0 / PN / ABEC 1
Running Accuracy: P6 / ABEC 3
Heat Stabilization: None – Up to 120 °C
Operating Temperature Range: -30 °C to +150 °C
Current Insulation: No Current Insulation
Version: Improved Interior Construction
Inner Ring: Removable on Both Sides

Load Type: Radial Loads Only
Axial Displacement: Permits axial displacement of the shaft relative to the housing in both directions

Suffix Meaning:
EC: Optimized internal design with more and/or larger rollers and modified roller/end flange contact
J: Pressed steel cage, roller centered, unhardened

Description:
The SKF NU2206ECJ is a single-row cylindrical roller bearing with NU design, featuring two rigid ribs on the outer ring and no ribs on the inner ring. This design allows the bearing to support high radial loads only while permitting axial displacement in both directions, making it ideal as a floating bearing in applications affected by thermal expansion.

It uses a pressed steel cage to separate the rollers, which helps reduce friction and allows higher operating speeds than full-complement cylindrical roller bearings. This bearing is commonly used in gearboxes, pumps, compressors, electric motors, and agricultural machinery.

Possible Use with Angle Ring:
When combined with a separately available HJ angle ring, this bearing can also be used as a support bearing capable of carrying radial loads and axial load in one direction.

   PACKAGE INCLUDES: ONE (1) SKF Bearing NU2206 ECJ
